Alligator
THE ALL NEW ALLIGATOR SERIES:
EXTREMELY FLAT – EXTREMELY FLEXIBLE.
Designed to easily dock under helicopters with low ground clearance and equipped with devices such as FLIR, radar, antennas and cameras.
The world's most compact electric aircraft tug has now become even more compact. Its patented clamp technology fixes the nose gear securely and smooth. The overall height of the alligator is so low that even extensive attachments below the aircraft fuselage do not obstruct the nose gear clamping.
- Full electric drive
- Radio remotely controlled
- Fully automatic nose gear engaging function: loads and unloads the nosewheel automatically with one tap on the remote
- Only 1 person required for operation
- Applicable for single or double nose wheel
- Hydraulic adjustment of the mouth opening depth for wheels with small diameter
- High powered electric motors
- No driving license required
- Minimal operating costs
- Park your aircraft using the last corner of your hangar and save space
- Quickest Return on Investment
Optional Equipment
- Ground power cable for gound power connection
- Automatic controls by ground markings (AGV functionality)
- Adaptations for special demands
- Spiral cable connection (15 m) between Mototok and control unit instead of radio remote control
- Saltwater resistance
Mototok Alligator in action.
New Nose gear clamping mechanism
With the Mototok Alligator you get a machine that has a completely newly developed mechanism to lift the nose wheel of a helicopter or aircraft. This mechanism allows a safe and smooth clamping of the nose wheel at an incredibly low height: The lifting platform of the Mototok Alligator is only 200 mm high. Thus, the alligator fits under virtually any aircraft regardless of which equipment such as FLIR, radar, antennas or similar is installed.
Very low construction height.
Only 200mm height in the platform area.
Thanks to its extremely low height in the area of the nose wheel platform, collisions with attached equipment are virtually impossible.
In this example, the FLIR hangs relatively low under the helicopter. However, the low design of the platform makes it possible to dock the Mototok to the nose wheel without having to fear a collision with the FLIR.
The lifting height of the platform is sufficient to ensure that the FLIR does not collide with the housing of the Mototok even when manoeuvring - i.e. even if the Mototok turns away under the fuselage. Free manoeuvring is possible.
Automated loading process –
Sensor monitored
The Mototok Alligator is operated exactly as you may know it from our other models SPACER, TWIN, and M: With the help of the radio remote control you move the tug up to the nose wheel of the aircraft. The automatic loading process is started by simply pressing a button on the remote control.
Depending on the size of the nose wheel, the 28 individually movable nose wheel clamps are gently pressed against the nose wheel to hold it securely.
Technical Data & Dimensions
|
Mototok Alligator 4000 |
||
|
Use for |
single & double nosewheel, |
|
|
Maximum towing capacity |
50 t |
|
|
Maximum nosewheel weight capacity |
3.5 t |
|
|
Dimensions |
width |
2812 mm |
|
lenght |
2505 mm |
|
|
height |
320 mm |
|
|
Lifting height, customizable |
up to 200 mm |
|
|
Platform height at the centerline |
149 mm |
|
|
Max width of the nosewheel |
800 mm |
|
|
Diameter of the nosewheel |
330 – 480 mm |
|
| Unladen weight |
2.300 kg |
|
|
Possible terrain |
Concrete, stone |
|
|
Tyres |
Puncture-proof tires |
|
|
Advanced radio remote control |
||
